UF Test Joint Boxes

For underground installation, for disconnecting the down conductor from the earth-termination system for measuring purposes.

Type GCI – with integrated, easily accessible test joint

Detachable with a key, including terminal for the down conductor and the earthing conductor, open (without bottom).

1 Produkt

Nr kat. 549001 UFTSK 7.10 FL40 300X220X120 GG

GTIN / EAN 4013364025554, Nr taryfy celnej (EU): 85359000, Waga brutto: 6.10 kg, Jednostka opakowaniowa: 1.00 pc(s)

Rysunki

Informacje dodatkowe

UF test joint boxes, GCI
UF test joint boxes for underground installation
with integrated, easily accessible test joint
terminal for the down conductor and earthing cable included,
open at the bottom
Material: GCI
Dimensions: 300 x 220 x 120 mm
Material of test joint: StSt

Brand: DEHN
Type: UFTSK 7.10 FL40 300X220X120 GG
Part No.: 549001
or equivalent.

Certyfikaty



Dane techniczne

Material GCI
Colour black (varnished) ●
Dimensions 300 x 220 x 120 mm
Clamping range Rd / Fl 7-10 / 30-40 mm
Max. permissible load 40 kN

Produkt 549001 został dodany do notatnika.

Idź do notatnika

Do koszyka dodano produkt 549001.

Idź do sklepu internetowego

Type GCI – without test joint

Open (without bottom).

1 Produkt

Nr kat. 549000 UFTSK 300X220X120 GG

GTIN / EAN 4013364025547, Nr taryfy celnej (EU): 85389099, Waga brutto: 6.20 kg, Jednostka opakowaniowa: 1.00 pc(s)

Rysunki

Informacje dodatkowe

UF test joint boxes, GCI, without test joint
UF test joint boxes for underground installation
without test joint
open at the bottom
Material: GCI
Dimensions: 300 x 220 x 120 mm

Brand: DEHN
Type: UFTSK 300X220X120 GG
Part No.: 549000
or equivalent.

Certyfikaty



Dane techniczne

Material GCI
Colour black (varnished) ●
Dimensions 300 x 220 x 120 mm
Max. permissible load 40 kN

Produkt 549000 został dodany do notatnika.

Idź do notatnika

Do koszyka dodano produkt 549000.

Idź do sklepu internetowego

Type plastic – with integrated, easily accessible test joint

Detachable with a key, including terminal for the down conductor and the earthing conductor, open (without bottom).

1 Produkt

Nr kat. 549050 UFTSK 7.10 FL40 197X197X204 K

GTIN / EAN 4013364128217, Nr taryfy celnej (EU): 85359000, Waga brutto: 2.18 kg, Jednostka opakowaniowa: 1.00 pc(s)

Rysunki

Informacje dodatkowe

UF test joint boxes, plastic
UF test joint boxes
for underground installation
with integrated, easily accessible
test joint terminal for the down conductor
and earthing cable included,
open at the bottom
Material: plastic
Dimensions: 197 x 197 x 204 mm
Material of test joint: StSt

Brand: DEHN
Type: UFTSK 7.10 FL40 197X197X204 K
Part No.: 549050
or equivalent.

Certyfikaty



Dane techniczne

Material plastic
Colour grey ●
Dimensions 197 x 197 x 204 mm
Clamping range Rd / Fl 7-10 / 30-40 mm
Max. permissible load 15 kN

Produkt 549050 został dodany do notatnika.

Idź do notatnika

Do koszyka dodano produkt 549050.

Idź do sklepu internetowego

Type plastic – without test joint

Open (without bottom).

1 Produkt

Nr kat. 549051 UFTSK 197X197X204 K

GTIN / EAN 4013364128224, Nr taryfy celnej (EU): 85389099, Waga brutto: 1.66 kg, Jednostka opakowaniowa: 1.00 pc(s)

Rysunki

Informacje dodatkowe

UF test joint boxes, plastic, without test joint
UF test joint boxes for underground installation
without test joint
open at the bottom
Material: plastic
Dimensions: 197 x 197 x 204 mm

Brand: DEHN
Type: UFTSK 197X197X204 K
Part No.: 549051
or equivalent.

Certyfikaty



Dane techniczne

Material plastic
Colour grey ●
Dimensions 197 x 197 x 204 mm
Max. permissible load 15 kN

Produkt 549051 został dodany do notatnika.

Idź do notatnika

Do koszyka dodano produkt 549051.

Idź do sklepu internetowego

Type StSt – with integrated, easily accessible test joint

Detachable with a key, including terminal for the down conductor and the earthing conductor, open (without bottom).

1 Produkt

Nr kat. 549090 UFTSK 7.10 FL40 200X200X105 V2A

GTIN / EAN 4013364128231, Nr taryfy celnej (EU): 85359000, Waga brutto: 3.73 kg, Jednostka opakowaniowa: 1.00 pc(s)

Rysunki

Informacje dodatkowe

UF test joint boxes, StSt
UF test joint boxes for
underground installation
with integrated, easily accessible test joint
terminal for the down conductor
and earthing cable included,
open at the bottom
Material: StSt
Dimensions: 200 x 200 x 105 mm
Material of test joint: StSt

Brand: DEHN
Type: UFTSK 7.10 FL40 200X200X105 V2A
Part No.: 549090
or equivalent.

Certyfikaty



Dane techniczne

Material StSt
Dimensions 200 x 200 x 105 mm
Clamping range Rd / Fl 7-10 / 30-40 mm
Max. permissible load 40 kN

Produkt 549090 został dodany do notatnika.

Idź do notatnika

Do koszyka dodano produkt 549090.

Idź do sklepu internetowego

Type StSt – without test joint

Open (without bottom).

1 Produkt

Nr kat. 549091 UFTSK 200X200X105 V2A

GTIN / EAN 4013364128248, Nr taryfy celnej (EU): 85389099, Waga brutto: 3.15 kg, Jednostka opakowaniowa: 1.00 pc(s)

Rysunki

Informacje dodatkowe

UF test joint boxes, StSt without test joint
UF test joint boxes for underground installation
without test joint
open at the bottom
Material: StSt
Dimensions: 200 x 200 x 105 mm

Brand: DEHN
Type: UFTSK 200X200X105 V2A
Part No.: 549091
or equivalent.

Certyfikaty



Dane techniczne

Material StSt
Dimensions 200 x 200 x 105 mm
Max. permissible load 40 kN

Produkt 549091 został dodany do notatnika.

Idź do notatnika

Do koszyka dodano produkt 549091.

Idź do sklepu internetowego
