Nr kat. 785721 APS CL1 MEHA
GTIN / EAN 4013364360198, Nr taryfy celnej (EU): 39269060, Waga brutto: 192.00 g, Jednostka opakowaniowa: 1.00 pc(s)
Wcześniejszy produktDane techniczne
Nominal voltage up to (UN ) | 1000 V |
Colour | Transparent |
Material | Polycarbonate |
Wall thickness | approx. 2 mm |
Arc fault protection class (box test 4 kA / 0.5 s – single-pole) | APC 1 |
Arc energy (Warc or WLBP ) | 158 kJ |
Visible light transmittance (VLT) | ≥ 75 % |
Standard | GS-ET-29, EN 166, EN 170 |
Nr kat. 785722 APS CL2 MAHA
GTIN / EAN 4013364360242, Nr taryfy celnej (EU): 39269060, Waga brutto: 294.00 g, Jednostka opakowaniowa: 1.00 pc(s)
Dane techniczne
Nominal voltage up to (UN ) | 1000 V |
Colour | blue |
Material | polycarbonate |
Wall thickness | approx. 2 mm |
Arc fault protection class (box test 7 kA / 0.5 s – single-pole) | APC 2 |
Arc energy (Warc or WLBP ) | 318 kJ |
Visible light transmittance (VLT) | ≥ 74.4 % |
Standard | GS-ET-29, EN 166, EN 170 |
